Inductors for Signal Line

PhotoCategoryApplicationTech SpecificationDimensions Code JIS/EIASeriesDownload
SDFL1005
Multilayer/STDInductors for Signal Line0.047 to 3.3μH 丨 10 to 25mA1005 [0402 inch]SDFL1005

SDFL+Series+of+Multilayer+Chip+Ferrite+Inductor

SDFL1608
Multilayer/STDInductors for Signal Line0.047 to 33μH 丨 1 to 50mA1608 [0603 inch]SDFL1608

Same as above

SDFL2012
Multilayer/STDInductors for Signal Line0.047 to 47μH 丨 4 to 300mA2012 [0805 inch]SDFL2012

Same as above

SDFL3216
Multilayer/STDInductors for Signal Line0.047 to 47μH 丨 5 to 300mA3216 [1206 inch]SDFL3216

Same as above

WL1608FS
Wire WoundInductors for Signal Line0.0049 to 22μH 丨 70 to 2600mA1608 [0603 inch]WL1608FS

WL-FS+Series+of+Wire+Wound+Chip+Ferrite+Inductor

MWSD0603F
Wire WoundInductors for Signal Line33 to 200nH 丨 110 to 340mA0.53×0.4×0.4MWSD0603F

MWSD-F+Series+of+Wire+Wound+Chip+Ferrite+Inductor

MWDS0703F
Wire WoundInductors for Signal Line27 to 560nH 丨 90 to 480mA0.76×0.43×0.57MWDS0703F

Same as above

MWSD1005F
Wire WoundInductors for Signal Line22 to 2200nH 丨 170 to 1600mA1.1×0.6×0.55MWSD1005F

Same as above

MWSD1005F-M01
Wire WoundInductors for Signal Line18 to 2200nH 丨 170 to 2200mA1.1×0.6×0.55MWSD1005F-M01

Same as above

MWSD1608F
Wire WoundInductors for Signal Line51 to 22000nH 丨 70 to 1050mA1.6×0.8×0.8MWSD1608F

Same as above

MWSD-FE1608
Wire WoundInductors for Signal Line2.2 to 47μH 丨 100 to 580mA1608 [0603 inch]MWSD-FE1608

MWSD-FE+Series+of+Wire+Wound+Chip+Ferrite+Inductor

MWSD-FE2012
Wire WoundInductors for Signal Line2.2 to 22μH 丨 340 to 1040mA2012 [0805 inch]MWSD-FE2012

Same as above

SDWL2012FW
Wire Wound/STDInductors for Signal Line0.27 to 68μH 丨 40 to 350mA2012 [0805 inch]SDWL2012FW

SDWL-FW+series+of+Wire+Wound+Chip+Ferrite+Inductor

SDWL2520FW
Wire Wound/STDInductors for Signal Line0.33 to 10μH 丨 300 to 700mA2520 [1008 inch]SDWL2520FW

Same as above

SDWL3216FW
Wire Wound/STDInductors for Signal Line1.5 to 18μH 丨 130 to 320mA3216 [1206 inch]SDWL3216FW

Same as above

SDWL3225FW
Wire Wound/STDInductors for Signal Line0.12 to12μH 丨 140 to 450mA3225 [1210 inch]SDWL3225FW

Same as above

MTNF
Wire WoundInductors for Signal Line3.7μH5.5×2.0×2.0
6.2×3.0×2.0
6.2×4.0×2.0		MTNF

MTNFseriesofNFMIAntenna
